Introducing AVX-10K: Your All-in-One Flight Line Test Solution
       Â
As the IFR4000 and IFR6000 legacy comes to a close by December 31, 2023, the AVX-10K takes centre stage, revolutionising avionics testing for fixed-wing, rotary, and UAV aircraft. Combining the best of its predecessors into a single, modular device, the AVX-10K offers unparalleled testing capabilities.
AVX-10K: ELEVATING AVIATION WITH 6 BENEFITS
Single Device, Multiple Capabilities
- Test communications, navigation, and surveillance systems with one comprehensive device.
- Minimise instrument purchases, calibrations, storage, and shipping logistics.
Remote Control Efficiency
- Connect via over-the-air methods, including the free VIAVI Mobile Tech app.
- Conduct testing from the cockpit, enabling a single technician to replace the traditional two, saving valuable hours.
User-Friendly Interface
- Intuitive GUI for rapid technician learning and increased productivity.
- Access testing templates and on-screen pass/fail indications for streamlined operations.
Global Troubleshooting Support
- Utilise Smart Access Anywhere for remote expert assistance from anywhere in the world.
- Enhance troubleshooting efficiency and reduce downtime.
Configurations and Templates
- Built-in templates for different aircraft configurations.
- Save time and effort by accessing personalised templates, ideal for shared instruments.
Cloud Integration for Enhanced Management
- Seamlessly integrate with VIAVI StrataSync for efficient test data and asset management.
- Ensure the AVX-10K is always up-to-date with the latest software and firmware for optimal performance.
         Â
THE AVX-10K COMES IN 4 PRE-CONFIGURED KITS, PICK THE TEST KITS THAT YOU NEED
AVX-10K-FLTS
Flight Line Test Set only configuration – allows customer to pick and choose what hardware and software options desired
AVX-10K-NAV
Communication, Navigation package includes the NAV/COMM software options shown and all NAV/COMM required hardware. This package is comparable to the IFR4000.
AVX-10K-SVLC
Surveillance package includes Transponder, ADS-B and DME software options and all required hardware like the IFR6000.
AVX-10K-CNS
Communication, Navigation & Surveillance configuration. Includes options for comparable functions to the IFR4000 & IFR6000. (TCAS, UAT and ELT are optional).
             Â
VIAVI AVX-10K Flight Line Test Set Documents
HOW DOES AVX-10K-CNS COMPARE TO THE PREDESSORS IFR6000 & IFR4000?
AVX-10K-CNS (All in one solution)
Features
- • Communication - AM/FM/SELCAL
- • Navigation- VOR/DME/ILS
- • Surveillance- XPDR/ADS-B/UAT/TCAS
- • Test Tools- VSWR/DTF
- • Mobile Tech App
- • StrataSyncy
- • Built-in GPS Receiver
Benefits
- • Comprehensive, configurable test solution
- • ADS-B/ADS-R/TIS-B Traffic and ELT
- • Troubleshooting and fault location
- • Remote testing in and around the aircraft
- • Technical and supporting documentation at your fingertips
- • Android™ and iOS® compatible
- • Asset and report management
- • Accurate testing of ADS-B positional data
IFR6000 - Discontinued 31st December
Features
- • Transponder Auto Test (DO-181E)
- • Automated ADS-B performance testing and reporting
- • Monitor and decode– ADS-B (DO-260A/B)– AC 20-165B surface/air auto test– UAT
- • Target generator– ADS-B 1090 MHz(DO-260A/B surface and air)– UAT 978 MHz (ADS-B, TIS-B, FIS-B)
- • Comprehensive GICB testy DME ground station simulation
- • UUT parametric tests
- • User programmable TCAS scenarios
- • Altitude encoder
- • Over-the-air, direct, or coupled testing
Benefits
- • Battery operation 6 hours plus
- • Provides a full FAR Part 43, Appendix F test
- • Verification of ADS-B/UAT installed systems
- • Avoid ATC interference with optional coupler
- • Data dump of transponder test results to PC
- • Software updates available via website
IFR4000 - Discontinued 31st December
Features
- • Morse code provides 1-4 characters transmitted in the VOR and ILS localizer mode
- • Generation of ARINC 596 Selective Calling Tones
- • Simulation of Localizer and Glideslope (CAT I, II, and III) Signals with variable DDM settings
- • Accurate measurement of VHF/UHF antenna and or feeder SWR (Standing Wave Ratio)
- • Simulation of marker beacon, selectable outer, middle, and inner marker tones
Benefit
- • Battery operation 8 hours plus
- • Guided test capability reduces total test time
- • Low cost ELT option
- • Software updates downloaded via website
- • Frequency counter provides external freque
SEE THE AVX-10K IN ACTION
                 Â
THE AVX-10K ADVANTAGE
Cost of Ownership Savings
- • Reduction of the number of assets to maintain
- • Reduced calibration costs, including storage, tracking, and shipping
- • Extended warranty options including quick turn around time and loaner test sets
- • Software defined standard platform for adding future test applications
User Productivity
- • Aircraft return-to-service efficiency improvements
- • Single comprehensive kit consisting of all hardware necessary to test multiple avionics systems
- • Remote operation using the free VIAVI Mobile Tech app allows a single technician to test what previously required two technicians
- • Use of templates provides consistency in testing with a known starting point for all test types
Asset and Report Management from StrataSync
Asset Management
- • Always be current with the latest software updates
- • Manage all your assets in one location
- • Share system test templates and unit configurations among test sets and locations
Report Management
- • Sync and upload all test data for transfer to your server
- • Provides detailed information of an aircraft's historical performance used in the creation of preventative maintenance plans
